Name: Cisco Catalyst 1300 48-port GE, Full PoE, 4x10G SFP+
SKU: C1300-48FP-4X
Price: 2064.70 EUR
Availability: InStock

Суич, тип

Fixed Port

Общ брой портове

52

Основни портове, тип

10/100/1000Base-T

Power Over Ethernet (PoE)

PoE+

Uplink портове

4xSFP+

Свободни (10GB) слотове

No

Управление

Yes

Stackable

Yes

Fans

Y

Захранване

Internal

Routing

Dynamic

Памет (Flash, RAM)

512 MB (Flash), 1 GB DDR4 (DRAM), 1.5MB (Packet buffer)

Капацитет за маршрутизиране/превключване, Gbps

176 Gbps

Пропускателна способност, Mpps

130.94 Mpps

MAC адреси

16 000 addresses

VLAN (брой, стандарти)

Support for up to 4093 VLANs simultaneously; Port-based and 802.1Q tag-based VLANs, MAC-based VLAN, protocol-based VLAN, IP subnet-based VLAN; Management VLAN; Private/Guest/unauthenticated/Auto surveillance/CPE/Voice/Dynamic/Multicast TV VLAN

QoS

8 hardware queues; Strict priority and WRR; Port-based, 802.1p VLAN priority-based, IPv4/v6 IP precedence/Type of Service (ToS)/DSCP-based, Differentiated Services (DiffServ), classification and remarking ACLs, trusted QoS Queue assignment based on DSCP

L2 мрежови стандарти

IEEE 802.3, IEEE 802.3u/ab/ad/z/x/af/at; IEEE 802.1D (STP)/1Q/p VLAN/w RSTP/s Multiple STP/X Port Access Authentication; RFC

IPv6 functionality

IPv6 host mode, IPv6 over Ethernet, dual IPv6/IPv4 stack; IPv6 neighbor and router discovery (ND); DAD, ICMP; DHCPv6; IPv6 over IPv4 network with ISATAP tunnel support; IPv6 QoS; ACL; First Hop Security; MLD

Сигурност

SSH, SSL, IEEE 802.1x (authenticator role):RADIUS authentication and accounting, MD5 hash, guest VLAN, unauthenticated VLAN, single/multiple host mode, and single/multiple sessions; MAC/Web-based authentication; STP; DHCP; IPSG; DAI; IPMB; SCT; SSD; ACLs

Размери (Ш, Д, В), mm

445 x 350 x 44 mm

Опция за монтаж

Rackmount

Weight

7.148 kg

Dimensions

0 x 0 x 0 cm

Warranty

99 months

Cisco Catalyst 1300 48-port GE, Full PoE, 4x10G SFP+
