Спецификации

Капацитет
Input from grid: Max. AC input overcurrent protection - 125A, Max. continuous input current - 90A, AC output voltage(nominal) - 230V/400V (340-440V), AC frequency (nominal) - 50Hz/60Hz (45-65Hz - range), Grid disconnection switchover time: <500ms
Х-ка 2
Input from inverter: Rated AC power - 40kW, Max. continuous input current@230V - 58A, Rated AC power in continuous backup operation - 40kW, Max. continuous input current in backup operation - 58A, Peak AC power/current(<10s) in backup operation - 44kW/63A
Х-ка 3
Communication: RS485
Х-ка 4
Manual control bypass switch
Х-ка 5
Cooling: Natural convection, Noise: <30dB
Х-ка 6
Operating temperature range: –40 °C~60 °C, Operating humidity(rh): Up to 100%, Maximum elevation: 3000m
Х-ка 7
IP65 Protection rating
Гаранция, м.
12 месеца
Приложение
за бизнеса и за дома
Х-ка 8
Dimensions(W/H/D): 365/486/120mm, Weight: 12kg
Х-ка 1
Input from grid: Max. AC input overcurrent protection - 125A, Max. continuous input current - 90A, AC output voltage(nominal) - 230V/400V (340-440V), AC frequency (nominal) - 50Hz/60Hz (45-65Hz - range), Grid disconnection switchover time: <500ms
