HUAWEI FusionSolar, безплатен телефон: 00 80 03 38 88 888, имейл: eu_inverter_support@huawei.com, Гаранционна процедураСпецификации
- КапацитетMax. Number of Connected Devices: 80
- Х-ка 2Communication Interface: 1x 10/100/1000 Mbps WAN, 1x 10/100/1000 Mbps LAN, RS485 (COMx3,1200/ 2400/4800/ 9600/19200/115200bps,1000m), 2G/3G/4G, Digital/Analog Input/Output (DIx4, DOx2, AI x4), Active DO - 12V, 100mA (connection with relay, sensor)
- Х-ка 3Communication Protocol: Ethernet (Modbus-TCP, IEC60870-5-104), RS485 (Modbus-RTU, IEC60870-5-103 (standard), DL/T645)
- Х-ка 4Interaction: LED Indicator x3 – RUN, ALM, 4G; Embedded Web; 1x USB2.0; APP (Communication by WLAN for Commissioning)
- Х-ка 5Operating Temperature Range: -40°C~60°C, Storage Temperature: -40°C~70°C, Relative Humidity (Non-condensing): 5%~95%, Max. Operating Altitude: 4000m
- Х-ка 6AC Power Supply: 100V - 240V, 50Hz/60Hz; DC Power Supply: 12V / 24V; Power Consumption: Typical 8W, Max. 15W
- Х-ка 7Protection Degree: IP20, Installation Options: Wall Mounting, DIN Rail Mounting,Tabletop Mounting
- Гаранция, м.24 месеца
- Приложениеза специализирана употреба
- Х-ка 8Dimensions (WxHxD): 225 x 160 x 44 mm, Weight: 2 kg
- Х-ка 1Max. Number of Connected Devices: 80
