HUAWEI FusionSolar, безплатен телефон: 00 80 03 38 88 888, имейл: eu_inverter_support@huawei.com, Гаранционна процедураСпецификации
- Тип на свързванеThree phase
- Ефективност98.6% max. efficiency, 98.2% European efficiency
- Мощност, W22 000 Wp Recommended max. PV power
- Вх.напрежение, VMax. input voltage: 1100 V, Start Voltage: 160 V, Operating voltage range: 160 V ~ 1000 V, Number of MPP Trackers: 2, Max. input per MPP Tracker: 1
- Изх. мощност, W12 000 W Rated output power
- Изх. мощност, VA13 200 VA Max. apparent power
- Изх.напрежение, VRated output voltage: 220 V AC / 380 V AC, 230 V AC / 400 V AC, 240 V AC / 415 V AC 3W/N + PE
- Честота, HzRated AC Grid Frequency: 50 Hz / 60 Hz
- Изх. ток, AMax. Output Current: 20.2 A
- Видове защитаAsymmetric load, Input-side disconnection device, Anti-islanding/DC reverse polarity/DC-AC surge/AC overcurrent/AC short-circuit/AC overvoltage/Arc fault protection, Residual current/Insulation/Connector temperature detectionl, Ripple receiver control
- ИндикаториLED Indicators
- Тип на охлажданеNatural convection
- Работна температура-25°C ~ 60°C
- Диапазон на влажността при експлоатация0 ~ 100%
- ИнтерфейсRS485, WLAN/Ethernet via Smart Dongle-WLAN-FE (Optional); 4G/3G/2G via Smart Dongle-4G (Optional), EMMA (Optional)
- СигурностEN/IEC 62109-1, EN/IEC 62109-2
- СтандартиGrid connection standards: IEC 61727, IEC 62116, MEA/PEA, G99, PGC Resolution No.07, NRS 097-2-1, EN 50549-1, VDE 4105, UTE15-712-1/VFR 2019, UNE 217002, NTS 631, RD244 (UNE 217001), PPDS, ROGA, TOR Erzeuger, CEI 0-21:2020-12 V1, C10/C11
- ЦвятWhite
- Размери (Ш, Д, В), mm490 x 460 x 130 mm
- Тегло, kg21 kg
- ДругиIP66 Protection Degree
- Гаранция, м.120 месеца
- Приложениеза бизнеса и за дома
- БатерияLUNA2000-5/10/15-S0 / LUNA2000-7/14/21-S1, Operating voltage range: 600 ~ 980V, Max. operating current: 20 A, Max. charging power: 12 000 W, Max .discharging power: 12 000 W
