HUAWEI FusionSolar, безплатен телефон: 00 80 03 38 88 888, имейл: eu_inverter_support@huawei.com, Гаранционна процедураСпецификации
- Тип на свързванеSingle phase
- Ефективност97.8% max. efficiency, 97.2% European weighted efficiency
- Мощност, W9000 Wp Recommended max. PV power
- Вх.напрежение, VMax. input voltage (PV): 600 V, Rated input voltage (PV): 360 V, MPPT Operating voltage range: 40 V ~ 560 V, Max. input number per MPP tracker: 1, Number of MPP trackers: 2
- Изх. мощност, W6000 W Rated output power (On Grid)
- Изх. мощност, VA6600 VA Max. apparent power (On Grid)
- Изх.напрежение, VRated output voltage: 220 Vac / 230 Vac / 240 Vac (On Grid)
- Честота, HzRated AC grid frequency (On Grid): 50 Hz / 60 Hz
- Изх. ток, AMax. output current: 30 A (On Grid)
- Видове защитаIP66, Anti-islanding/DC reverse polarity/AC overcurrent/AC short-circuit/AC overvoltage/Arc fault protection, Battery charging from grid, Insulation/Residual current monitoring, AC/DC surge protection (TYPE II)
- ИндикаториLED indicators
- Тип на охлажданеNatural convection
- Работна температура-25 ~ 60 °C
- Диапазон на влажността при експлоатация0% RH ~ 100% RH
- ИнтерфейсRS485, WLAN via inverter built-in WLAN module Ethernet via Smart Dongle-WLAN-FE (Optional); 4G / 3G / 2G via Smart Dongle-4G (Optional)
- СигурностEN/IEC 62109-1, EN/IEC 62109-2
- СтандартиGrid connection standards: G98, G99, G100, EN 50549-1, CEI 0-21, VDE-AR-N-4105, C10/11, P140, UTE C15-712, TOR Erzeuger, IEC61727, IEC62116
- ЦвятWhite
- Размери (Ш, Д, В), mm425 x 376.5 x 150 mm
- Тегло, kg15 kg
- Гаранция, м.120 месеца
- Приложениеза бизнеса и за дома
- БатерияCompatible battery: LUNA2000-5/10/15-S0, LUNA2000-7/14/21-S1; Operating voltage range: 350 ~ 560 Vdc, Max operating current: 16.5 A, Max charge Power: 6000 W, Max discharge Power: 6600 W
