Integrated antennas: 2.4 GHz, gain 2 dBi + 5 GHz, gain 3 dBi
1x Gigabit Ethernet uplink (10/100/1000BASE-T autosensing), PoE, 3x Gigabit Ethernet local ports (10/100/1000BASE-T), including one PoE out port; 1x passive pass-through port, RJ-45 (back to bottom)
802.11a, 802.11b/g, 802.11n, 802.11ac, Authentication and security: 802.1x, 802.11r and 802.11i
Wi-Fi Protected Access 2 and 3 (WPA2 and WPA3), 802.1x, RADIUS Authentication, Authorization, and Accounting (AAA); 802.11r and 802.11i; Torx security screw, included with the access point; Kensington lock slot to lock device to mounting bracket; AES; EAP
802.3af/at; Power draw: 8.5W (maximum, without PoE out)
Managed by Cisco Business access points and mesh extenders easily without a physical controller, using Cisco Business Mobile app. Optional multisite remote management is available through the Cisco FindIT Network Management.
MU-MIMO: Maximum number of associated wireless clients: 200 per Wi-Fi radio, for a total of 400 clients per access point, Maximum number of associated Cisco Business mesh extenders: 25 per Access Point, up to 8 hops
